Manitou 120AETJ Electric Boom Lift

Manitou 120AETJ

800+ Machine Fleet

We have over 800 of our own machines plus a large, efficient transport fleet, giving us the ability to meet all of your requirements at a moments notice.

Professional & Friendly

We re-invest into staff traning on a regular basis, ensuring that our work family is always ahead of the industry, friendly and here to help you with the best solution.

30+ Years In The Industry

We’ve been working in the industry for over 30 years now, and APL as a company has been around for over 10+ years - Giving you the confidence that we’re the right people for the job!

ANY TIME, ANY PLACE

We’re not restricted to providing access equipment at any point. Our team are dedicated and solution focused to all of APL’s customers.

STANDARD SPECIFICATIONS

KEEP SCROLLING DOWN to see why the Manitou 120AETJ is the perfect Electric Boom Lift for your project

Turning Radius

Featuring an optimised turning radius which translates to increased manoeuvrability within tight spaces, for easier movement down narrow aisles and building sites to name but a few.

STANDARD FEATURES

The Manitou 120 AETJ articulated electric platform has a capacity of 200 kg with a working height of up to 11.95m

Easy to Use

The 120AETJ is designed bearing simplicity and particularly ease of use in mind. With this machine you'll be on board and off in no time, even if you are a novice operator.

STANDARD FEATURES

The overhang height of 4.77 m combined with the working offset of 7 m offers a range of possibilities to the operator

Safety

Audible alarm and illuminated indicator lamp (leveling, overload, lowering) Pothole protection with automatic operation

STANDARD FEATURES

The narrow design of its chassis (1.2 m) and of its elevation structure provides a high level of manoeuvrability in confined and crowded spaces

DOWNLOAD SPEC SHEET

Battery Powered
Diesel Powered
Dual Fuel
Hybrid
4x4
Jack Legs
Non Marking Tyres
Power-To-Platform
Basket Rotation

REACH DIAGRAM

DIMENSIONS

PERFORMANCE

  • Working Height 11.95m
  • Platform Height 9.95m
  • Articulation Height 4.77m
  • Outreach 7.00m
  • Jib Tilting +70°/-70°
  • Jib Movement +70°/-70°
  • Basket Rotation 140°
  • Turret Rotation 355°
  • Lift Capacity 200kg
  • Number of Persons (Indoor/Outdoor) 2/2
  • 1. Overall Width 1.20m
  • 2. Overall Length 5.48m
  • 3. Overall Height 1.99m
  • 4. Overall Length When Folded 3.74m
  • 5. Overall Height When Folded 2.16m
  • 6. Inside Turning Radius 1.55m
  • 8. Outside Turning Radius 3.44m
  • 9. Ground Clearance 10cm
  • Wheelbase 1.65m
  • Maximum Slope Accessible 25%
  • Weight 6,660kg
