| H. Working Height | 21.70m |
| A. Platform Height | 19.70m |
| C. Platform Height (Lowered) | 2.58m |
| DxF. Platform Length x Width (Deck Retracted) | 3.38m x 1.16m |
| ExF. Platform Length x Width (Deck Extended) | 4.88m x 1.16m |
| H1. Height Stowed (Rails Up) | 3.74m |
| H3. Height Stowed (Rails Down) | 3.01m |
| LxB. Machine Length x Base | 3.74m x 1.20m |
| G. Wheelbase | 2.67m |
| M. Ground Clearance (Stowed) | 148mm |
| N. Ground Clearance (Raised) | 235mm |
| Lift Capacity | 500kg |
| Gradeability | 25% |
| Weight | 9,120kg |
Drivable at the full height of 19.70m
Platform size of 3.38m x 1.16m with an added 1.5m extending deck
Proportional controls and intuitive control box design for easy operation
Benefit from a lift capacity of 500kg across the whole of the deck, suitable for 2 persons + 340kg. Even on the extending deck you can benefit from this large lift capacity.
On-board 230V power supply on platform to power tools
Proportional controls and intuitive control box design for easy operation
