| Working Height | 26.38m |
| Platform Height | 24.38m |
| Horizontal Outreach | 15.80m |
| Up and Over Height | 9.78m |
| Swing (Continuous) | 360° |
| Lift Capacity | 227kg |
| Platform Rotator | 180° |
| Jib Overall Length | 1.83m |
| Jib Range of Articulation | 130° (+70°/-60°) |
| A. Platform Size | 0.91m x 1.83m |
| B. Overall Width | 2.49m |
| C. Tailswing | 0.76m |
| D. Height Stowed | 3.00m |
| E. Length Stowed | 11.13m |
| F. Wheelbase | 3.05m |
| G. Ground Clearance | 0.28m |
| Gradeability | 45% |
| Weight | 15,558kg |
JLG’s patented QuikStick® boom design significantly reduces lift/lower cycle times
Best in class reach envelope for enhanced productivity
Customer-preferred controls mean fewer buttons and switches used to position the platform and less time spent learning to use the platform controls
Lower hydrocarbon, carbon monoxide, particulate and NOx emissions with Stage IIIB-compliant engine
Equipped with hydrostatic drive for easy, precise, infinitely-variable-speed manoeuvrability. Go from ground to over 26m in under 50 seconds an enjoy industry best reach envelope with exclusive QuickStik boom
Conquer rough terrain with standard oscillating axle and four-wheel drive, delivering optimised grip and stability
