| Working Height | 21.95m |
| Platform Height | 20.12m |
| Horizontal Outreach | 17.37m |
| A. Platform Size | 0.91m x 2.44m |
| B. Stowed Width | 2.44m |
| C. Tailswing | 1.19m |
| D. Stowed Height | 2.57m |
| E. Stowed Length | 10.34m |
| F. Wheelbase | 2.44m |
| G. Ground Clearance | 0.41m |
| Rotation (Continuous) | 360° |
| Platform Rotation | 170° |
| Jib Length | 1.50m |
| Jib Range | +65°/-60° |
| Gradeability | 50% |
| Inside Turning Radius | 2.82m |
| Outside Turning Radius | 5.05m |
| Axle Oscillation | 7.62cm |
| Lift Capacity | 227kg |
| Max No. of Persons | 2 |
| Weight | 12,111kg |
Skyjack telescopic booms are ideal when extended horizontal and vertical outreach are key for the job site. These offer precise positioning paired with high capacity platforms and industry-leading reach.
Drivable at full height
50% Gradeability
This means the boom lift controls are always in the orientation of the operator regardless of position of turret over chassis. This reduces operator confusion by eliminating the need for colour coded arrows to determine drive versus joystick direction.
An axle-based drive system with an operator controlled locking differential on the rear axle and limited slip differential on the front axle. This drive system has been proven as durable, low maintenance, and capable of navigating any job site terrain.
170° Platform Rotation
