| A. Working Height | 11.40m |
| B. Platform Height | 9.40m |
| C. Lowered Platform Height | 1.50m |
| D. Overall Width | 2.20m |
| E. Overall Length | 3.71m |
| F. Stowed Height (Rails Up) | 2.70m |
| G. Stowed Height (Rails Down) | 1.99m |
| H. Platform Width (Inside Dimension) | 1.70m |
| I. Platform Length (Inside Dimension) | 5.70m |
| Deck Extension (x2) | 1.22m |
| Ground Clearance | 0.20m |
| Wheelbase | 2.27m |
| Gradeability | 30% |
| Turning Radius (Inside) | 4.01m |
| Turning Radius (Outside) | 6.30m |
| Lift Capacity | 909kg |
| Weight | 5,684kg |
Drivable at full height of 9.40m with roll out decks fully extended
"No Spin" rear differential and limited slip front differential
Independent/auto levelling outriggers for work on uneven ground and slopes
Featuring dual 1.22m roll out extension deck increasing the platform size to 5.7m (L) x 1.70m (W)
Benefit from a large lift capacity of 909kg allowing multiple persons and their tools to work more productively
Foam-filled, rough-terrain grip lug tyres capable of tackling difficult terrain coupled with a gradeability of 30%
