| A. Working Height | 17.98m |
| B. Platform Height | 16.15m |
| C. Lowered Platform Height | 2.12m |
| D. Overall Width | 2.30m |
| E. Overall Length | 4.50m |
| F. Stowed Height (Rails Up) | 3.20m |
| G. Stowed Height (Rails Down) | 2.43m |
| H. Platform Width (Inside Dimension) | 1.82m |
| I. Platform Length Extended (Inside Dimension) | 7.40m |
| Platform Length Stowed (Inside Dimension) | 4.36m |
| Ground Clearance | 0.26m |
| Wheelbase | 3.02m |
| Gradeability | 35% |
| Turning Radius (Inside) | 3.33m |
| Maximum Drive Height | Full Height |
| Lift Capacity | 680kg |
| Maximum No. of Persons | 5 |
| Weight | 8,301kg |
Large 7.40m total working platform length with dual deck extended
Independent/auto-levelling outriggers
Overall lift capacity of 680kg comprised of 454kg on the main platform and 227kg on the front extension deck
Benefit from a 680kg lift capacity allowing a maximum of 5 people to work simultaneously on the platform
7.40m (L) x 1.82m (W) platform dimensions when dual 1.5m deck extensions are extended
Robust axle based 4WD system with "no spin" and limited slip differentials delivering excellent job site terrainability
