| H. Working Height | 22.00m |
| A. Platform Height | 20.00m |
| DxF. Platform Length x Width (Deck Retracted) | 4.30m x 1.19m |
| ExF. Platform Length x Width (Deck Extended) | 6.10m x 1.19m |
| H1. Height Stowed (Rails Up) | 3.82m |
| H3. Height Stowed (Rails Down) | 2.99m |
| LxB. Machine Length x Base | 4.72m x 1.25m |
| G. Wheelbase | 3.18m |
| M. Ground Clearance (Stowed) | 20mm |
| Lift Capacity | 600kg |
| Gradeability | 25% |
| Weight | 12,350kg |
Drivable at the full height of 22.00m
Platform size of 4.30m x 1.19m with an added 1.8m extending deck
Proportional controls and intuitive control box design for easy operation
Benefit from a lift capacity of 600kg across the whole of the deck, suitable for 2 persons + 440kg. Even on the extending deck you can benefit from this large lift capacity.
On-board 230V power supply on platform to power tools
Proportional controls and intuitive control box design for easy operation
