| A. Working Height | 9.90m |
| B. Platform Height | 7.90m |
| C. Lowered Platform Height | 1.23m |
| D. Overall Width | 1.76m |
| E. Overall Length | 3.35m |
| F. Stowed Height (Rails Up) | 2.38m |
| G. Stowed Height (Rails Down) | 1.61m |
| H. Platform Width (Inside Dimension) | 1.42m |
| I. Platform Length (Inside Dimension) | 2.44m |
| Extension Deck | 1.52m |
| Ground Clearance | 0.20m |
| Gradeability | 50% |
| Turning Radius (Inside) | 1.52m |
| Turning Radius (Outside) | 3.96m |
| Lift Capacity | 567kg |
| Maximum No. of Persons | 4 |
| Maximum Drive Height | Full Height |
| Weight | Weight |
Drivable at full height with 1.52M roll out deck fully extended
Up to 50% gradeability
Independent/auto levelling outriggers
Max working height of 9.90m suitable for a number of external applications
Increased productivity thanks to a 567KG platform capacity allowing for multiple men and their tools to be lifted
Foam-filled rough-terrain tyres as standard allowing for increased manoeuvrability on uneven surfaces.
