| H. Working Height | 27.50m |
| A. Platform Height | 25.20m |
| C. Platform Height Lowered | 2.75m |
| DxF. Platform Length x Width (Retracted) | 6.15m x 2.50m |
| ExF. Platform Length x Width (Extended) | 8.25m x 2.50m |
| H1. Height Stowed | 3.89m |
| H3. Height Stowed (Rails Folded) | 3.13m |
| LxB. Machine Length x Base | 6.57m x 2.65m |
| G. Wheelbase | 4.50m |
| M. Ground Clearance (Stowed) | 195mm |
| Lift Capacity | 1000kg |
| Gradeability | 30% |
| Weight | 21,910kg |
Controlbox with quick disconnect for easy operation from ground
Driveable at full height of 25.20m
6.15m x 2.50m platform dimensions with an additional 2.10m deck extension
Benefit from 30% gradeability allowing the machine to be used in a number of different scenarios
Offering a 1000kg lift capacity, the HL-275 is suitable for multiple men and their tools
Four wheel drive with oscillating axle and self-levelling jacks
