| Working Height | 9.77m |
| Platform Height | 7.77m |
| A. Stowed Height | 2.33m |
| B. Platform Railing Height | 1.10m |
| C. Stowed Height (Rails Folded) | 1.98m |
| D. Platform Size (W x L) | 0.76m x 2.30m |
| E. Deck Extension | 0.90m |
| F. Overall Width | 0.81m |
| G. Overall Length | 2.30m |
| H. Wheelbase | 1.88m |
| I. Ground Clearance | 0.09m |
| Lift Capacity | 230kg |
| Maximum Drive Height | Full Height |
| Gradeability | 25% |
| Turning Radius (Inside) | 0m |
| Turning Radius (Outside) | 2.06m |
| Weight | 2,135kg |
Max working height of 9.77m suitable for a number of internal applications
Benefit from a lift capacity of 230kg ideal for a range of scenarios
Non-marking solid tyres perfect for work on sensitive flooring
Electric power for zero emissions and near-silent running indoors
Boost efficiency with direct electric drive
Get into more places with compact dimensions and precise control system
