| Working Height | 15.72m |
| Platform Height | 13.72m |
| Working Outreach | 7.62m/8.27m* |
| Up and Over Height | 7.30m |
| Swing | 355° |
| Lift Capacity | 249kg |
| Platform Rotator | 180° |
| A. Platform Size | 0.76m x 1.83m |
| B. Overall Width | 2.35m |
| C. Tailswing | 0m |
| D. Height Stowed | 2.27m |
| E. Length Stowed | 6.58m |
| F. Wheelbase | 2.36m |
| G. Ground Clearance | 0.42m |
| Jib | 1.24m |
| Range of Articulation | 144° (+76°,-69°) |
| Gradeability | 45% |
| Axle Oscillation | 10cm |
| Turning Radius (Inside) | 2.06m |
| Turning Radius (Outside) | 4.78m |
| Weight | 6,495kg* |
Variable speed engine control for improved fuel efficiency reducing operating costs.
50%* faster full elevation time (*actuals might vary) increasing workers efficiency.
250 kg in basket vs 230 kg before allowing you to carry more tools or materials to stay on a job longer.
Cut fuel consumption and operating costs with variable engine control.
Increase your work envelope with more horizontal reach. *may vary depending on model)
Reduce maintenance with DuraTough turntable hood. High impact resistance and protects components.
