| (A) Working Height | 20.80m |
| (B) Platform Height | 18.80m |
| (C) Horizontal Outreach | 12.80m |
| Up and Over Height | 7.00m |
| Platform Size | 1.80m x 0.85m |
| Jib Articulation | 150° |
| Cage Rotation | 100° |
| (D) Height Stowed | 2.15m |
| (F) Width | 2.27m |
| (H) Length Stowed (Transport Position) | 5.30m |
| (J) Length Stowed | 6.70m |
| Turning Radius | 4.00m |
| Gradeability | 45% |
| Lift Capacity | 225kg |
| Weight | 6,660kg* |
The Diesel-only option incorporates a versatile and efficient Tier 4 Final/Euro Stage V compliant engine to deliver maximum traction and gradeability, making it ideal for rough or uneven ground.
Weighing just 6,660kg, the HR21 4x4 combines innovative weight and space-saving design with an excellent turning circle to deliver outstanding manoeuvrability on-site and lower transportation costs.
Proportional controls deliver smooth, measured operation while 160º cage rotation and a 150º fly-boom allow precise positioning anywhere in its vast working envelope.
4WD for rough terrain
Multi-award winning operator protection
3.89m outside turning radius
