Skyjack SJ8841RT

Specifications

A. Working Height

14.50m

B. Platform Height

12.50m

C. Lowered Platform Height

1.75m

D. Overall Width

2.20m

E. Overall Length

3.71m

F. Stowed Height (Rails Up)

2.90m

G. Stowed Height (Rails Down)

2.22m

H. Platform Width (Inside Dimension)

1.70m

I. Platform Length (Inside Dimension)

5.70m

Deck Extension (x2)

1.22m

Ground Clearance

0.20m

Wheelbase

2.27m

Gradeability

30%

Turning Radius (Inside)

4.01m

Turning Radius (Outside)

6.30m

Lift Capacity

681kg

Weight

6,173kg

Delivery & Collection

We offer UK-wide delivery on all our products and pride ourselves on the ability to provide same-day delivery in certain scenarios. Collection is available within 7 days, in line with our CPA, ensuring your equipment arrives safely. All deliveries are fully insured and treated with care.

Health & Safety

Please follow all health and safety guidelines when using our products. Always wear the appropriate protective equipment and adhere to local regulations to ensure safe handling and operation.

Health & Safety downloads

Application & uses

Diesel Powered

Diesel Powered

Reliable diesel performance

4 x 4 Drive

4 x 4 Drive

All-terrain capability

Jack Legs

Jack Legs

Stability on uneven ground

Power-To-Platform

Power-To-Platform

Has power to platform

Working envelope

Working envelope

Dimension drawing

Dimension drawing

MACHINE INFORMATION

The Skyjack SJ8841RT is a diesel-powered rough terrain scissor lift with a maximum working height of 14.5 meters and a platform capacity of 681 kilograms, suitable for demanding outdoor applications. It features a large platform (5.7 meters in length, 1.7 meters in width) with dual 1.22-meter extension decks, extending the platform to 8.14 meters. The lift has a 30% gradeability and is equipped with a 4-wheel drive system and rough-terrain tires for stability on uneven surfaces. Additional features include a turning radius of 6.3 meters and the ability to be driven at full height, enhancing productivity on site.

STANDARD FEATURES

Drivable at full height of 12.50m with roll out decks fully extended

"No Spin" rear differential and limited slip front differential

Independent/auto levelling outriggers for work on uneven ground and slopes

MORE SPACE

Featuring dual 1.22m roll out extension deck increasing the platform size to 5.7m (L) x 1.70m (W)

LARGE CAPACITY

Benefit from a large lift capacity of 909kg allowing multiple persons and their tools to work more productively

MORE SPACE

Foam-filled, rough-terrain grip lug tyres capable of tackling difficult terrain coupled with a gradeability of 30%
