| A. Working Height | 10.00m |
| B. Platform Height | 8.00m |
| C. Overall Length | 2.48m |
| D. Overall Width | 1.15m |
| E. Overall Height (Rails Down) | 1.78m |
| Overall Height (Rails Up) | 2.32m |
| F. Platform Size (Length x Width) | 2.27m x 1.12m |
| G. Deck Extension | 0.90m |
| Ground Clearance (Stowed) | 0.10m |
| Ground Clearance (Raised) | 0.019m |
| Wheelbase | 1.87m |
| Turning Radius (Inside) | 0m |
| Turning Radius (Outside) | 2.20m |
| Gradeability | 25% |
| Weight | 2,655kg |
1.12m x 2.27m platform dimensions with self-lock gate for added safety
Non-Marking tyres suitable for a range of indoor applications
0.90m extending deck for increased access and manoeuvrability
Easy to access Platform Extension Footlock allowing for quick deployment of the 0.90m extending deck
Inside and Outside turning radius of 0m and 2.20m providing better mobility in tight spaces
Low weight of just 2,655kg
