| A. Working Height | 22.00m |
| B. Platform Height | 20.00m |
| C. Overall Length | 4.80m |
| D. Overall Width | 2.27m |
| E. Overall Height (Rails Down) | 2.84m |
| Overall Height (Rails Up) | 3.68m |
| F. Platform Size (Length x Width) | 4.35m x 1.85m |
| G. Extension Deck | 2.00m |
| Lift Capacity | 750KG |
| Ground Clearance | 0.22m |
| Wheelbase | 3.13m |
| Turning Radius (Inside) | 2.15m |
| Turning Radius (Outside) | 5.35m |
| Gradeability | 30% |
| Weight | 13,000kg |
Platform size of 4.35m x 1.85m with additional 2.00m deck extension. Self-lock gate on platform for added safety
Self-levelling hydraulic outriggers for use on uneven ground
AC Power to Platform for increased productivity
European III Emission Engine
Give your operators and their tools the power they require without the need for an external power source thanks to the onboard generator
Benefit from a working height of 22m providing access for a number of different scenarios
