| Working Height | 10.97m |
| Platform Height | 9.14m |
| Up and Over Height | 4.01m |
| Horizontal Outreach | 6.77m |
| Swing | 350° |
| Lift Capacity | 230kg |
| Platform Rotator (Hydraulic) | 180° |
| Jib Overall Length | 1.22m |
| Jib Range of Articulation (Vertical) | 144° (+84°/-60°) |
| A. Platform Size | 0.76m x 1.22m |
| B. Overall Width | 1.22m |
| C. Tailswing | 0m |
| D. Stowed Height | 2.01m |
| E. Stowed Length | 5.74m |
| F. Wheelbase | 1.65m |
| G. Ground Clearance | 0.10m |
| Gradeability | 25% |
| Turning Radius (Inside) | 1.52m |
| Turning Radius (Outside) | 3.10m |
| Weight | 7,100kg* |
Increased accessibility with the optional JibPLUS® with side-to-side movement and near-vertical jib operation
Standard Automatic Traction Control for enhanced terrain performance and increased manoeuvrability
High-efficiency direct electric drive with longer duty cycles for increased productivity
Zero emissions for environmentally-friendly equipment
144 Degrees
350 Degrees
