Skyjack SJ30ARJE Electric Boom Lift

Platform Specifications

Working Height 11.00m
Platform Height 9.00m
Platform Height 6.26m
Up and Over Height 3.99m
Horizontal Outreach 6.26m
A. Platform Size 0.76m x 1.17m
B. Stowed Width 1.19m
C. Tailswing 0m
D. Stowed Height 1.98m
E. Transport Height 2.50m
F. Stowed Length 5.51m
G. Transport Length 3.78m
H. Wheelbase 1.65m
Ground Clearance 10.16cm
Turret Rotation 355° Non-Continuous
Platform Rotation 180°
Jib Length 1.25m
Jib Range of Motion (Vertical) 142° (+77°/-65°)
Jib Range of Motion (Horizontal) 180°
Gradeability (Counterweight Facing Up) 35%
Gradeability Counterweight Facing Down) 25%
Gradeability Counterweight Facing Down) 1.52m
Turning Radius (Outside) 3.23m
Lift Capacity 227kg
Max No. of Persons (Indoors/Outdoors) 2/1
Wind Rating 12.5m/s
Weight 5,588kg*
Battery Powered
Diesel Powered
Dual Fuel
Hybrid
4x4
Jack Legs
Non Marking Tyres
Power-To-Platform
Basket Rotation
Enquire Now
×

Call our hire desk
0800 085 3709

MACHINE INFORMATION

STANDARD FEATURES

Skyjack articulating booms offer precise positioning capabilities packaged in a high capacity boom with industry-leading up-and-over reach. The tight turning radius on these machines and minimal tailswing make them ideal for maneuvering in confined areas.

Featuring 180° Horizontal Jib articulation and 142° vertical articulation

The SJ30ARJE offers 11.00m working height along with 6.26m horizontal reach and 3.99m of Up and Over height

SKYRISER

Ensures that the riser and main pivot point connecting the fly boom to the riser travel in a straight vertical line. Movement in a true vertical manner, without drifting forward or back, reduces the amount of repositioning the operator needs to do in order to stay close to a building facade, improving productivity.

EASYDRIVE

This means the boom lift controls are always in the orientation of the operator regardless of position of turret over chassis. This reduces operator confusion by eliminating the need for colour coded arrows to determine drive versus joystick direction.

ACCESSORYZERS

Skyjack offers a full line of ACCESSORYZERS™ to improve your machine’s versatility. These manufacturer-approved accessories are designed to add functionality to your machine and convenience for the operator. Whether it’s helping you get materials to the work site, protecting equipment from the weather, or enhancing productivity, Skyjack has the right accessory for the job.

WORKING ENVELOPE

DIMENSIONS

HIRE Skyjack SJ30ARJE Electric Boom Lift

WITH AERIAL PLATFORMS
