| Working Height | 20.46m |
| Platform Height | 18.64m |
| Working Outreach | 12.10m |
| Up and Over Height | 8.09m |
| Swing (Continuous) | 360° |
| Lift Capacity | 230kg |
| Platform Rotator | 180° |
| Jib Overall Length | 1.83m |
| Jib Range of Articulation | 130° (+70°,-60°) |
| A. Platform Size | 0.91m 1.83m |
| B. Overall Width | 2.49m |
| C. Tailswing | 0m |
| D. Height Stowed | 2.57m |
| E. Length Stowed | 8.82m |
| F. Wheelbase | 2.48m |
| G. Ground Clearance | 0.30m |
| Gradeability | 45% |
| Weight | 10,455kg* |
Narrow chassis option for easy of mobility in congested work areas
Choice of jib or non jib models for increased versatility
Optional four wheel drive with oscillating axle for superb terrain performance
Equipped with hydrostatic drive for easy, precise, infinitely-variable-speed manoeuvrability
Conquer rough terrain with standard oscillating axle and four-wheel drive, delivering optimised grip and stability. Work in tighter spaces thanks to compact design with zero tail-swing
Customer-preferred controls mean fewer buttons and switches used to position the platform and less time spent learning to use the platform controls
