| A. Working Height | 13.80m |
| B. Platform Height | 11.80m |
| C. Lowered Platform Height | 1.37m |
| D. Overall Width | 1.19m |
| E. Overall Length | 2.40m |
| F. Height Stowed (Rails Up) | 2.48m |
| G. Height Stowed (Rails Down) | 2.21m |
| H. Platform Width (Inside Railing) | 1.06m |
| I. Platform Inside Length (Retracted) | 2.19m |
| Deck Extension | 0.90m |
| Ground Clearance (Pothole Raised) | 8.10cm |
| Ground Clearance (Pothole Deployed) | 1.90cm |
| Wheelbase | 1.85m |
| Gradebability | 25% |
| Turning Radius (Inside) | 0.54m |
| Turning Radius (Outside) | 2.58m |
| Maximum Drive Height | Full Height |
| Lift Capacity | 227kg* |
| Weight | 3,400kg* |
Drivable at full height of 11.80m with roll our deck fully extended
Variable speed, front wheel hydraulic drive
Solid rubber, non-marking tyres, pothole protection and a gradeability of 25%
Benefit from a working height of 13.80m ideal for a range of indoor projects
Offering a lift capacity of 227kg providing access for 2 men and their tools
Compact machine dimensions of 1.19m x 2.40m
